Feeding & Rotating
NC bending uses manual feed and rotate (electric rotation optional). CNC bending uses fully automatic servo feeding and rotating.
NC Semi-Automatic Tube Bender
Hydraulic Bending, Casting Head, ±0.1° Accuracy
Nine NC tube bender models from Φ38 to Φ219 mm, each an NC tube bending machine (also called an NC pipe bending machine) and a cost-effective choice for small and medium batch pipe bending in steel, stainless steel, copper and aluminum.
The Range
All NC Tube Bender Models
Semi-automatic hydraulic pipe bending machines with manual feeding and rotating (electric rotation optional), plus hydraulic clamping and mandrel shift. The casting machine head holds bending accuracy to ±0.1°. The NC series is the lower-cost route for small and medium batches across the full Φ38 to Φ219 mm scale.
115NC NC Semi-Automatic Tube Bender
View Details
130NC NC Semi-Automatic Tube Bender
View Details
168NC NC Semi-Automatic Tube Bender
View Details
219NC NC Semi-Automatic Tube Bender
View Details
38NC NC Semi-Automatic Tube Bender
View Details
50NC NC Semi-Automatic Tube Bender
View Details
63NC NC Semi-Automatic Tube Bender
View Details
75NC NC Semi-Automatic Tube Bender
View Details
89NC NC Semi-Automatic Tube Bender
View DetailsModel Comparison
Compare All Nine NC Tube Bender Models
The model number is the maximum tube OD in mm. Carbon steel and stainless capacities differ by wall thickness. Figures are the rated values for each model.
| Model | Max Carbon SteelΦ × wall, mm | Max StainlessΦ × wall, mm | Mandrel Lengthmm | Max Bend Radiusmm | Motor PowerkW | Weightkg |
|---|---|---|---|---|---|---|
| 38NC | Φ38.1 × 2.0 | Φ31.75 × 1.5 | 1850 | 175 | 4 | 545 |
| 50NC | Φ50.8 × 2.0 | Φ35 × 2.2 | 2250 | 200 | 5.5 | 765 |
| 63NC | Φ63.5 × 2.5 | Φ38 × 2.0 | 2950 | 220 | 5.5 | 1000 |
| 75NC | Φ76.2 × 3.0 | Φ51 × 2.0 | 3400 | 280 | 7.5 | 2000 |
| 89NC | Φ88.9 × 3.0 | Φ57 × 2.0 | 3520 | 300 | 11 | 2200 |
| 115NC | Φ115 × 6.0 | Φ88.9 × 2.0 | 3750 | 500 | 22 | 7000 |
| 130NC | Φ130 × 8.0 | Φ102 × 3.0 | 4230 | 500 | 22 | 8500 |
| 168NC | Φ168 × 14.0 | Φ135 × 10.0 | 4700 | 800 | 30 | 12000 |
| 219NC | Φ219 × 20.0 | Φ219 × 12.0 | 5500 | 1000 | 55 | 18000 |
Every NC bender reaches accuracy up to ±0.1°, bends up to 185° and stores 16 preset bend angles at 15 MPa working pressure. Speeds vary with pipe size and wall thickness, so confirm the final configuration for your tube with our engineers before ordering.
How It Works
How An NC Semi-Automatic Tube Bender Works
An NC bender bends under power like a CNC machine, but the operator handles feeding and rotating. This semi automatic pipe bending machine is a simpler, lower-cost build for small and medium batches. The heavy casting head and hydraulic bend arm of the NC pipe bender still deliver ±0.1° repeatable bends.
- 1
Operator Feeds & Rotates
The operator sets feed length and rotation between bends by hand (electric rotation optional).
- 2
Hydraulic Clamp & Mandrel
Hydraulic clamping holds the tube while the mandrel shifts inside it, so the wall does not collapse or wrinkle. Every NC model works as a mandrel bender, and the page on mandrel tube bending explains when a mandrel is needed.
- 3
Hydraulic Bend On A Casting Head
The rigid casting head bends the set angle under hydraulic power, up to ±0.1° accuracy.
- 4
Repeat To The Program
The NC control repeats the stored angle bend after bend for consistent parts across a batch.
NC vs CNC
What Is Different Between NC And CNC
Both bend the same pipe to the same precision. The difference is how much the operator does and what that means for batch size and budget.
Bending & Accuracy
Both bend hydraulically to ±0.1°. The NC casting head gives the same repeatable bend.
Best Batch Size
NC suits small and medium batches and mixed parts. CNC pays off on large, repeatable production runs.
Investment
NC is the affordable entry into precision bending. Step up to CNC when volume grows.
Selection Guide
How To Choose Your NC Bender
Start from your pipe size and your batch, then let our engineers confirm the model and tooling.
- By Pipe Size
The model number is the max tube OD, from 38NC up to the heavy 219NC. Pick the model that covers your largest pipe.
- By Material
Carbon steel capacity is higher than stainless at the same model, so tell us both material and wall thickness.
- By Batch & Budget
Small to medium batches and mixed work suit NC. High-volume repeat parts justify a CNC upgrade.
- By Automation
Add optional electric rotation for faster, more consistent multi-plane bends without going full CNC.
Materials
Your Pipe Material Decides The Die Set
As on every Telhoo bender, die material is matched to your pipe. Tell us what you bend and we supply the matching die set.
01
You bendCarbon steel pipe
Telhoo fits
45# steel dies as standard, Cr12 optional for longer tooling life on high-volume work.
02
You bendStainless steel pipe
Telhoo fits
Aluminum copper alloy mandrel and wiper so there is no galling on the stainless surface.
03
You bendCopper & aluminum pipe
Telhoo fits
Nylon or polished dies protect soft copper and aluminum tube for HVAC and decorative work.
Every machine ships with mandrel, wiper die, sensors, spanner and operation manual.
Applications
What NC Tube Benders Are Used For
Telhoo tube benders form round, square and profile tube in mild steel, stainless steel, copper and aluminum for these industries worldwide.
NC Bend Test VideoFootage of the 115NC hydraulic bender with the operator feeding the tube.
Automotive Exhaust & Frames
Muffler and exhaust pipe (often mandrel-bent), seat frames, roll-cage tube and chassis tube in round and profile sections.
HVAC & Refrigeration
Air-conditioning coils, heat pump lines and copper or aluminum refrigeration tube.
Furniture & Fitness Equipment
Chair and table frames, gym racks and equipment tube in round and profile sections.
Shipbuilding & Marine
Thick-wall carbon steel pipe and pipe spools for marine, offshore and structural fabrication.
Boiler & Heat Exchanger
Serpentine and coil tube for boilers, heat exchangers and power equipment.
Construction & Handrail
Stair rails, guardrails and architectural tube in stainless and mild steel.
How We Deliver
From Inquiry To Installation
1
Requirement & Pipe Analysis
We review your tube size, wall thickness, material, bend radius and target output.
2
Model & Tooling Proposal
We confirm the model and match bend, clamp, pressure and mandrel dies.
3
Manufacturing & Assembly
Your machine is built and assembled in our 30,000 m² factory.
4
Sample Bending & Test
We bend your sample parts and inspect them before shipment, FAT on request.
5
Export Packing & Shipping
Heavy-duty seaworthy packing, full documents and door-to-door logistics.
6
Install, Train & Support
Overseas installation, operator training and long-term spare parts.
How Your Machine Is Shipped
01Crating & Bracing
Each machine is wrapped, braced and lifted into a custom case so nothing shifts in transit.
02Iron-Frame Packing
Heavy machines get an iron-frame base and sealed case, rated for long ocean freight.
03Container Loading
We load 20ft, 40ft and open-top containers in our own yard and send photos before departure.
04Worldwide Shipping
Machines leave Zhangjiagang by sea to buyers in 65+ countries, with complete export paperwork.
Why Telhoo
Built And Supported By The Same Factory
We design and build the machine in Zhangjiagang and handle the tooling and after-sales ourselves.
- In-house R&D, machining and assembly
- CE and ISO9001 certified
- Non-standard and OEM machines built to your line
Telhoo By The Numbers Zhangjiagang, China
Experience
35+
Years manufacturing pipe processing machinery
Facility
30,000 m²
Modern production plant with in-house R&D
Export
65+
Countries with Telhoo machines
Response
24 h
Usual reply time for a quotation
Request A Quote
Tell Us What You Need To Make
Send your tube or pipe specs and an engineer will reply with a machine or process and a quotation, usually within one working day.
- 1Send Your Requirements
Share tube size, wall thickness, material, bend radius and quantity.
- 2Engineering Review
We check feasibility and tooling and choose the machine or process.
- 3Quotation In 24h
You receive a detailed quotation, usually within one working day.
NC Bender FAQ
NC Tube Bender Questions
An NC bender is semi-automatic. It uses hydraulic bending with manual feeding and rotating (electric rotation optional), reaching accuracy up to ±0.1° at a lower investment. A CNC bender is fully automatic with electric feeding and rotating and touch-screen control. NC is ideal for small and medium batches. CNC suits high-volume multi-bend production.
Nine models from Φ38 to Φ219 mm, matching the CNC scale, in mild steel, stainless steel, copper and aluminum. Send your exact pipe diameter, wall thickness and bend radius and we will confirm the right model.
Yes. Every Telhoo NC tube bender is a hydraulic pipe bender. A hydraulic cylinder drives the bend arm on a rigid casting head for repeatable ±0.1° bends on pipe up to Φ219 mm. Unlike small manual hydraulic pipe benders, these are full industrial semi-automatic machines.
Yes. Electric rotation, extra tooling stacks and non-standard configurations are available. Tell us your parts and output and our engineers will propose a setup.
Stainless work-hardens and needs roughly twice the bending force of mild steel at the same section, so every model in the range carries two ratings. The 38NC takes Φ38.1 × 2.0 mm in mild steel but Φ31.75 × 1.5 mm in stainless. The 168NC takes Φ168 × 14 mm against Φ135 × 10 mm. Always quote the material with the tube size.
It depends on the model, whether you add electric rotation, and the tooling for your tube. An NC bender costs less than the CNC machine of the same size because the operator feeds and rotates by hand. Send your tube size, wall thickness and material and we reply with a model and a price.
Yes. We bend your sample parts and inspect them before shipment, and a factory acceptance test is available on request. Send the sample tube and drawing with your inquiry.
