NC Semi-Automatic Tube Bender

89NC NC Semi-Automatic Tube Bender

NC semi-automatic tube bender for tube up to Φ88.9 × 3 mm at 30°/s, mandrel length 3520 mm. Sized for scaffolding, agricultural frames and heavier handrail work. Hydraulic bending with NC digital angle control, repeatable to ±0.1° through a 185° bend.

Max bending
Φ88.9X3 mm
Mandrel length
3520 mm
Bending speed
30 °/s
Bending precision
±0.1°
Max bending degree
185°
Pipe material
mild steel, stainless steel, copper, aluminum ...
  • CE, ISO9001, UL & EAC marked
  • Non-standard machine customizable
  • Overseas installation & training
Download Catalogue
Overview

Product Details

Overview

The 89NC tube bender is an NC hydraulic machine rated Φ88.9 × 3 mm in mild steel and Φ57 × 2 mm in stainless, running at 30°/s on an 11 kW drive with a 3520 mm mandrel.

Φ88.9 mm is three-and-a-half inch nominal pipe, so this size lands in scaffolding, pipe support and structural work. Bend speed is well down from the small models by design: pushing a heavy-wall Φ89 mm pipe round at small-tube speed causes wrinkling and inconsistent springback, and no set of dies will rescue that.

Specifications

NC Semi automatic

B Hydraulic auxiliary driving

Max bending
Φ88.9X3 mm
Mandrel length
3520 mm
Bending speed
30 °/s
Bending precision
±0.1°
Max bending degree
185°
  • Working light
  • Water cooling
  • Pipe material: mild steel, stainless steel, copper, aluminum …
  • Round / square / rectangle / profile … pipes and bars
  • CE, ISO90001, EAC, UL marked

Optional equipment

OPTIONAL

MP Auto rotating pipe

L
Left direction bending
P
Punching
C
Cutting

Safty cover
Stopper (length measurement)
Fan / Water / Oil cooling system
Bend 1.0XD radius, or more tight radius
Tie rod bars (support arm)

Tooling

TOOLS
Standard tool: 45# steel
Optional tool: Cr12 material
Stainless steel pipe: mandrel & wiper- Aluminum copper alloy steel
Aluminum pipe: bend die, clamp die and pressure die – nylon material
 Standard: Sealing ring, sensors, spanner, operation manual

Applications

Where The 89NC NC Semi-Automatic Tube Bender Goes To Work

From automotive exhaust lines to shipyard structures, Telhoo machines form round, square and profile tube in mild steel, stainless steel, copper and aluminum for repeatable, high-volume production.

Sample bent steel, stainless, copper and aluminum tube parts produced on Telhoo pipe bending machines
Bent tube chair frame produced on a Telhoo pipe bending machine
Real PartsFrom loose bends to finished frames — round, square and profile tube in steel, stainless, copper and aluminum.

Automotive Exhaust & Frames

Muffler and exhaust pipe, seat frames and chassis tube in round and profile sections.

HVAC & Refrigeration

Air-conditioning coils, heat pump lines and copper or aluminum refrigeration tube.

Furniture & Fitness Equipment

Chair and table frames, gym racks and equipment tube with clean, consistent bends.

Shipbuilding & Marine

Thick-wall carbon steel pipe for marine, offshore and structural fabrication.

Boiler & Heat Exchanger

Serpentine and coil tube for boilers, heat exchangers and power equipment.

Construction & Handrail

Stair rails, guardrails and architectural tube in stainless and mild steel.

How We Deliver

From Inquiry To Installation

1

Requirement & Pipe Analysis

We review your tube size, wall thickness, material, bend radius and target output.

2

Model & Tooling Proposal

We confirm the right model and match bend, clamp, pressure and mandrel dies.

3

Manufacturing & Assembly

Your machine is built and assembled in our 30,000 m² factory.

4

Sample Bending & Test

We bend your sample parts and inspect them before shipment, FAT on request.

5

Export Packing & Shipping

Heavy-duty seaworthy packing, full documents and door-to-door logistics.

6

Install, Train & Support

Overseas installation, operator training and long-term spare parts.

Why Telhoo

A Pipe Bending Partner, Not Just A Machine

Jiangsu Telhoo has manufactured CNC and NC pipe bending machines for over 35 years and exports to buyers in more than 65 countries. Every machine is backed by in-house R&D, full tooling support and after-sales service.

  • In-house R&D, machining and assembly
  • CE, ISO9001, UL and EAC certified
  • Non-standard and OEM machines built to your line
Telhoo By The NumbersZhangjiagang, China
Experience
35+

Years manufacturing pipe processing machinery

Facility
30,000 m²

Modern production plant with in-house R&D

Export
65+

Countries served across five continents

Response
24 h

Typical reply time on your quotation

Certifications

Quality You Can Verify

Every Telhoo machine is built under an ISO 9001 quality system and CE certified for the European market, with UL and EAC compliance available. Full certificates and test reports are provided with your order.

  • ISO 9001:2015
  • CE Marked
  • UL
  • EAC
Request A Quote

Get A Tailored Quote For The 89NC NC Semi-Automatic Tube Bender

Send us your pipe diameter, wall thickness, material and bend radius. Our engineers confirm the right model, tooling and options, and reply with a detailed quotation.

  • Reply within 24 hours by a real engineer
  • Free tooling and configuration advice
  • Your enquiry is kept strictly confidential
Tell Us Your Requirement

Fields marked * are required.

Export & Delivery

From Our Factory To Your Floor

Your machine is tested, crated and loaded in our own Zhangjiagang yard, then shipped by sea with full export documents — so it arrives ready to install.

Telhoo pipe bending machine being crated and braced for export01

Crating & Bracing

The machine is wrapped, braced and lifted into a custom case so nothing shifts in transit.

Iron-frame export packaging for a Telhoo CNC pipe bending machine02

Iron-Frame Packing

An iron-frame base and sealed case, rated for long ocean freight.

Container loading of a Telhoo CNC pipe bending machine at the factory03

Container Loading

Loaded into 20ft, 40ft or open-top containers in our own yard, with photos before departure.

Telhoo machines leaving the factory by container truck for worldwide export04

Worldwide Shipping

Shipped by sea to buyers in 65+ countries, with complete export paperwork.

Iron-frame packaging, container loading and export documentation are a standard part of every Telhoo order — supported by our own foreign-trade team.

FAQ

89NC NC Semi-Automatic Tube Bender — Common Questions

Φ88.9 × 3.0 mm in carbon steel and Φ57 × 2.0 mm in stainless. Φ88.9 mm is three-and-a-half inch nominal pipe, which is why this model is common in pipe spool and scaffolding work rather than in furniture.

The 38NC runs at 74 °/s and this machine at 30 °/s. Larger sections need more force and more controlled metal flow; pushing a heavy-wall Φ89 mm pipe round at small-tube speed causes wrinkling and inconsistent springback. The slower rate is deliberate, not a limitation of the hydraulics.

Yes. Scaffold tube is typically Φ48.3 mm and structural members run to Φ89 mm, both inside range. Maximum bend radius is 300 mm and mandrel length 3520 mm, which covers most structural bends.

A flat, level industrial floor is normally enough at this size — a dedicated foundation only becomes necessary further up the range. The machine should be levelled and anchored so that repeated bending does not walk it out of position.

Round bar can be bent with suitable tooling, but the process is different: there is no bore to collapse, so no mandrel is needed, while the force required is much higher for the same outside diameter. Tell us the material and section and we confirm feasibility.
