NC Semi-Automatic Tube Bender

168NC NC Semi-Automatic Tube Bender

The heaviest wall in the NC range: tube up to Φ168 × 14 mm on a 4700 mm mandrel. Bending runs at 4°/s so thick-section tube has time to form instead of collapsing. Built for boiler, shipbuilding and heavy structural work. Angle repeatability ±0.1°, 185° maximum bend.

Max bending
Φ168X14 mm
Mandrel length
4700 mm
Bending speed
4 °/s
Bending precision
±0.1°
Max bending degree
185°
Pipe material
mild steel, stainless steel, copper, aluminum ...
  • CE, ISO9001, UL & EAC marked
  • Non-standard machine customizable
  • Overseas installation & training
Download Catalogue
Overview

Product Details

Overview

The 168NC tube bender is an NC hydraulic pipe bender rated Φ168 × 14 mm in mild steel and Φ135 × 10 mm in stainless, 12 tonnes, 30 kW, with a 4700 mm mandrel and an 800 mm maximum bend radius.

A Φ168 × 14 mm steel pipe weighs around 53 kg per metre, so a six-metre length is over 300 kg — this is not a bender that gets hand-loaded, and overhead lifting or support rollers are part of the installation. Offshore structures, heavy pipe spool and power plant pipework are the typical jobs, all low volume and high value.

Specifications

NC Semi automatic

B Hydraulic auxiliary driving

Max bending
Φ168X14 mm
Mandrel length
4700 mm
Bending speed
4 °/s
Bending precision
±0.1°
Max bending degree
185°
  • Working light
  • Water cooling
  • Pipe material: mild steel, stainless steel, copper, aluminum …
  • Round / square / rectangle / profile … pipes and bars
  • CE, ISO90001, EAC, UL marked

Optional equipment

OPTIONAL

MP Auto rotating pipe

L
Left direction bending
P
Punching
C
Cutting

Safty cover
Stopper (length measurement)
Fan / Water / Oil cooling system
Bend 1.0XD radius, or more tight radius
Tie rod bars (support arm)

Tooling

TOOLS
Standard tool: 45# steel
Optional tool: Cr12 material
Stainless steel pipe: mandrel & wiper- Aluminum copper alloy steel
Aluminum pipe: bend die, clamp die and pressure die – nylon material
 Standard: Sealing ring, sensors, spanner, operation manual

Applications

Where The 168NC NC Semi-Automatic Tube Bender Goes To Work

From automotive exhaust lines to shipyard structures, Telhoo machines form round, square and profile tube in mild steel, stainless steel, copper and aluminum for repeatable, high-volume production.

Sample bent steel, stainless, copper and aluminum tube parts produced on Telhoo pipe bending machines
Bent tube chair frame produced on a Telhoo pipe bending machine
Real PartsFrom loose bends to finished frames — round, square and profile tube in steel, stainless, copper and aluminum.

Automotive Exhaust & Frames

Muffler and exhaust pipe, seat frames and chassis tube in round and profile sections.

HVAC & Refrigeration

Air-conditioning coils, heat pump lines and copper or aluminum refrigeration tube.

Furniture & Fitness Equipment

Chair and table frames, gym racks and equipment tube with clean, consistent bends.

Shipbuilding & Marine

Thick-wall carbon steel pipe for marine, offshore and structural fabrication.

Boiler & Heat Exchanger

Serpentine and coil tube for boilers, heat exchangers and power equipment.

Construction & Handrail

Stair rails, guardrails and architectural tube in stainless and mild steel.

How We Deliver

From Inquiry To Installation

1

Requirement & Pipe Analysis

We review your tube size, wall thickness, material, bend radius and target output.

2

Model & Tooling Proposal

We confirm the right model and match bend, clamp, pressure and mandrel dies.

3

Manufacturing & Assembly

Your machine is built and assembled in our 30,000 m² factory.

4

Sample Bending & Test

We bend your sample parts and inspect them before shipment, FAT on request.

5

Export Packing & Shipping

Heavy-duty seaworthy packing, full documents and door-to-door logistics.

6

Install, Train & Support

Overseas installation, operator training and long-term spare parts.

Why Telhoo

A Pipe Bending Partner, Not Just A Machine

Jiangsu Telhoo has manufactured CNC and NC pipe bending machines for over 35 years and exports to buyers in more than 65 countries. Every machine is backed by in-house R&D, full tooling support and after-sales service.

  • In-house R&D, machining and assembly
  • CE, ISO9001, UL and EAC certified
  • Non-standard and OEM machines built to your line
Telhoo By The NumbersZhangjiagang, China
Experience
35+

Years manufacturing pipe processing machinery

Facility
30,000 m²

Modern production plant with in-house R&D

Export
65+

Countries served across five continents

Response
24 h

Typical reply time on your quotation

Certifications

Quality You Can Verify

Every Telhoo machine is built under an ISO 9001 quality system and CE certified for the European market, with UL and EAC compliance available. Full certificates and test reports are provided with your order.

  • ISO 9001:2015
  • CE Marked
  • UL
  • EAC
Request A Quote

Get A Tailored Quote For The 168NC NC Semi-Automatic Tube Bender

Send us your pipe diameter, wall thickness, material and bend radius. Our engineers confirm the right model, tooling and options, and reply with a detailed quotation.

  • Reply within 24 hours by a real engineer
  • Free tooling and configuration advice
  • Your enquiry is kept strictly confidential
Tell Us Your Requirement

Fields marked * are required.

Export & Delivery

From Our Factory To Your Floor

Your machine is tested, crated and loaded in our own Zhangjiagang yard, then shipped by sea with full export documents — so it arrives ready to install.

Telhoo pipe bending machine being crated and braced for export01

Crating & Bracing

The machine is wrapped, braced and lifted into a custom case so nothing shifts in transit.

Iron-frame export packaging for a Telhoo CNC pipe bending machine02

Iron-Frame Packing

An iron-frame base and sealed case, rated for long ocean freight.

Container loading of a Telhoo CNC pipe bending machine at the factory03

Container Loading

Loaded into 20ft, 40ft or open-top containers in our own yard, with photos before departure.

Telhoo machines leaving the factory by container truck for worldwide export04

Worldwide Shipping

Shipped by sea to buyers in 65+ countries, with complete export paperwork.

Iron-frame packaging, container loading and export documentation are a standard part of every Telhoo order — supported by our own foreign-trade team.

FAQ

168NC NC Semi-Automatic Tube Bender — Common Questions

Φ168 × 14.0 mm in carbon steel, Φ135 × 10.0 mm in stainless. Machine weight is 12000 kg with a 30 kW drive and a maximum bend radius of 800 mm.

A 14 mm wall at Φ168 mm needs enormous force and very controlled metal flow. At this size the bend itself is a slow, deliberate operation; the cycle time of the job is dominated by handling and setup, not by degrees per second.

A Φ168 × 14 mm steel pipe weighs around 53 kg per metre, so a six-metre length is over 300 kg. Overhead lifting or a pipe support roller arrangement is normally required — this is not a machine that is hand-loaded.

Offshore and marine structures, heavy pipe spool, power plant pipework, and large structural curves. These are low-volume, high-value parts where an NC machine's lower cost per part number beats CNC automation.

That is the maximum the standard machine accepts. Larger radii on this pipe size are usually produced on a pipe rolling machine instead, which forms a long sweeping curve in passes rather than pulling one bend around a die.
